Analog level gauge for black water tank 10–180 Ω, black dial/black bezel

Mærke: Osculati SKU: 27.320.05

Price:
Sale price177,00 kr

Description

Analog level gauge for black water tank is a round panel instrument for monitoring the liquid level in a black water or waste water tank. The analog dial instrument features a black face, black bezel, and clear white level markings for LOW, MID, and FULL.

The instrument operates with a sensor signal of 10–180 Ω and can be used in both 12 V and 24 V installations. The dial has optional red or yellow backlighting. The desired backlight color is selected by connecting the orange or yellow wire, respectively. For 24 V installations, a voltage-reducing series resistor is used as indicated in the wiring instructions.

The external instrument diameter is 57 mm, and the instrument depth is 45 mm. The catalog hole size is 51 mm, while the installation manual specifies a recommended panel cutout of Ø52 mm. There must be at least 55 mm of free space behind the panel, and the mounting is intended for panel thicknesses of 0.5–20 mm. The instrument is inserted from the front and secured with a ring from the rear.

The wiring harness is connected to the back of the instrument. The black wire is connected to the level sensor, red to positive supply, and blue to ground. The instrument is supplied with a connection cable set and series resistor. A separate level sensor with a 10–180 Ω signal is required to perform the level measurement.

Compatible level sensors

Documented vertical sensors: 50.202.25, 50.202.28, 50.202.32, 50.202.38 and 50.202.48.
Documented capacitive sensors: 50.204.82, 50.204.83 and 50.204.84.

Key features

Analog display of level in black water and waste water tanks
Sensor signal: 10–180 Ω
Voltage: 12/24 V
Black face and black bezel
Level markings: LOW, MID and FULL
Selectable red or yellow backlighting
External diameter: 57 mm
Recommended panel cutout: Ø52 mm
Mounted from the front and secured from the rear

Did you know?

... that many of our products can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Did you know

... that many of our items can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Alpina Marineudstyr

Ask us about the product

Send us your question. The product will automatically be included in your message.

Analog level gauge for black water tank 10–180 Ω, black dial/black bezel
Analog level gauge for black water tank 10–180 Ω, black dial/black bezel Item no. 27.320.05

Description

Produkt: Analog niveaumåler til sortvandstank
Produkttype: Analogt panelinstrument
Anvendelse: Niveauvisning i sortvands- og spildevandstank
Volt: 12/24 V
Udvendig diameter: 57 mm
Dybde: 45 mm
Farve: Sort skive og sort frontkrans
Signalområde: 10–180 Ω
Visning: Analog viser
Niveaumarkeringer: LOW, MID og FULL
Baggrundsbelysning: Valgbar rød eller gul
Katalogets hulmål: 51 mm
Anbefalet paneludskæring: Ø52 mm
Fri plads bag panel: Mindst 55 mm
Paneltykkelse: 0,5–20 mm
Montering: Panelmontering med fastgørelsesring fra bagsiden
Kompatibilitet: Niveausensorer med 10–180 Ω signal; 50.202.25, 50.202.28, 50.202.32, 50.202.38, 50.202.48, 50.204.82, 50.204.83 og 50.204.84
Leveringsindhold: Niveaumåler, tilslutningskabelsæt og seriemodstand
