This analog ammeter with shunt measures current in a 12/24 V electrical system on a symmetrical scale from −50 to +50 A. The zero point is positioned at the top center, allowing both negative and positive current directions to be read directly on the dial scale.
The instrument is supplied with an 8/32 V shunt. The shunt carries the measuring current around the instrument itself and is suitable for the majority of ammeters on the market. The instrument voltage of 12/24 V and the shunt's rating of 8/32 V describe different parts of the set.
The black dial features white numbers and scale markings, as well as a luminous pointer. The dial can be backlit with red or yellow light, allowing the instrument lighting to be matched to the rest of the panel.
The ammeter has an outer diameter of 57 mm and is designed for flush mounting in a mounting hole of Ø51 mm. Dimension P is 45 mm. The black bezel provides a uniform black-on-black look in the instrument panel.
Key featuresAnalog dial scale from −50 to +50 A
For 12/24 V electrical systems
Supplied with 8/32 V shunt
Black dial and black bezel
Red or yellow backlight
Outer diameter: 57 mm
Mounting hole: Ø51 mm
Dimension P: 45 mm
For instrument panel mounting
