Analog ammeter with shunt ±80 A, black dial and polished bezel

Mærke: Osculati SKU: 27.321.24

Price:
Sale price631,00 kr

Description

This analog ammeter with shunt is a panel-mounted pointer instrument for measuring current in 12/24 V electrical systems. The bipolar scale ranges from -80 A to +80 A, and the instrument features a black dial and a polished bezel.

The ammeter is supplied with an 8/32 V shunt. The dial has selectable red or yellow backlighting, allowing the illumination to be matched to other instrumentation. The orange wire activates the red lighting, while the yellow wire activates the yellow lighting.

The instrument's outer front diameter is 57 mm, and the specified instrument depth is 45 mm. The nominal hole diameter is 51 mm, while the installation manual requires a 52 mm cutout. Therefore, please check the instrument and the mounting dimensions before cutting the panel. There must be at least 55 mm of clearance behind the panel, and the mounting supports a panel thickness of 0.5–20 mm.

The instrument is inserted from the front of the panel and secured from the back with a fastening ring. The instrument housing has an alignment tab that must be marked and positioned correctly during installation. The wiring harness connects to the port on the back of the instrument.

The blue wire is used for ground, the red for positive supply, and the black for the sensor. When installing in a 24 V system, series resistors must be used: 150 Ω on the instrument's positive supply and 2 kΩ in the lighting circuit.

Key features

Analog, panel-mounted ammeter
Bipolar measuring scale: ±80 A
For 12/24 V electrical systems
Supplied with 8/32 V shunt
Black dial and polished bezel
Selectable red or yellow backlighting
Outer diameter: 57 mm
Mounting cutout diameter: 52 mm
Fastening from the back with a ring

Did you know?

... that many of our products can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Did you know

... that many of our items can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Alpina Marineudstyr

Ask us about the product

Send us your question. The product will automatically be included in your message.

Analog ammeter with shunt ±80 A, black dial and polished bezel
Analog ammeter with shunt ±80 A, black dial and polished bezel Item no. 27.321.24

Description

Produkt: Analogt amperemeter med shunt
Produkttype: Amperemeter
Anvendelse: Måling og visning af strøm i elektriske 12/24 V-systemer
Volt: 12/24 V
Ampere: ±80 A
Udvendig diameter: 57 mm
Dybde: 45 mm
Farve: Sort skive, blank ramme
Montering: Panelmontering med fastgørelsesring fra bagsiden
Nominel huldiameter: 51 mm
Udskæringsdiameter ved montering: 52 mm
Paneltykkelse: 0,5-20 mm
Fri plads bag panel: Min. 55 mm
Shunt: 8/32 V, medfølger
Baggrundsbelysning: Valgbar rød eller gul
Ledningsfunktioner: Blå til stel, rød til positiv forsyning, sort til sensor, orange til rød belysning og gul til gul belysning
Modstande ved 24 V: 150 Ω på positiv instrumentforsyning og 2 kΩ i belysningskredsløbet
Kompatibilitet: Elektriske 12/24 V-systemer og paneltykkelse 0,5-20 mm
