This illuminated rocker switch has an ON/OFF/ON contact function and three fixed positions. It is intended for general electrical functions and has three electrical terminals.
The switch has a current capacity of 15 A. The rear-facing Faston connections allow for connection using appropriate flat pin connectors. No specific system voltage or size of the Faston connectors is documented.
A transparent silicone cap seals the switch against water and allows the illumination to be visible through the rocker arm. Light source technology and light color are not specified, and the switch has no documented IP rating.
The variant has three fixed ON/OFF/ON positions without a documented spring return. It can therefore be used where an electrical function needs to be maintained in one of the two ON positions with a central OFF position.
Key featuresIlluminated rocker switch
Contact function: ON/OFF/ON
Three fixed contact positions
Three electrical terminals
Current capacity: 15 A
Rear-facing Faston connections
Transparent silicone cap
Water-sealed
