Nylon deck filler with integrated breather and click-open cap for deck-mounted boat fuel system filling. This FUEL variant is white and features clear FUEL marking on the cap, making the filling point's purpose easy to identify.
The integrated breather combines fuel filling and tank venting into a single unit. The design features a main filler neck and a separate, smaller breather neck beneath the shared base. The diameter of the breather neck is not specified.
The cap operates via a click-open mechanism with no documented key or threaded operation. The base measures 110 × 70 mm, while the protrusion above the mounting surface is 18 mm. The main filler neck diameter is Ø 38 mm; this measurement refers to the neck itself and not a documented mounting hole.
The filler is made of white nylon. Upon installation, the neck diameter, breather connection, and existing fuel system must be checked, as the hose inner diameter and breather neck measurements are not provided.
Key featuresFor deck-mounted fuel filling
Integrated tank breather
Click-operated opening
Main neck with Ø 38 mm diameter
Base: 110 × 70 mm
Protrusion: 18 mm
Made of white nylon
Clear FUEL marking on the cap
