This fuel gauge with white dial and polished bezel is an electric fuel level instrument for dashboard mounting in boats. The instrument displays the fuel level based on the signal from a resistive tank sender and can be set to either 240–33 Ω or 0–190 Ω. It can be used in both 12 V and 24 V systems.
The instrument has an outer diameter of 57 mm and an installation depth of 45 mm. The catalogued panel cutout is Ø 51 mm, while the nominal cut-out dimension in the installation instructions is Ø 52 mm. Therefore, please check the instrument and the mounting dimension before cutting the panel. There must be at least 55 mm of free space behind the panel, and the mounting is intended for a panel thickness of 0.5–20 mm.
The instrument is inserted from the front of the panel and secured from the back with a ring. The white instrument dial is combined with a polished/chrome-plated bezel, and this variant features red backlighting only.
The electrical connection includes a black wire to the sensor, a red wire to the positive supply, and a blue wire to ground or negative. For 24 V installation, the 24 V circuit is used with 150 Ω and 2 kΩ resistors.
The gauge is compatible with resistive fuel level senders that provide either a 240–33 Ω or 0–190 Ω signal. The selectable sender curve makes it possible to adapt the instrument to the documented signal type in the existing tank installation.
Key featuresElectric fuel level instrument for panel mounting
Selectable 240–33 Ω or 0–190 Ω sender signal
For 12/24 V systems
White instrument dial and polished/chrome-plated bezel
Red backlighting only
Outer diameter: 57 mm
Panel cutout: Ø 51 mm catalog dimension
Installation depth: 45 mm
Mounted from the front and secured with a ring from the back
