Fuel level gauge with black dial and polished bezel is an analogue marine instrument for displaying the fuel level from a resistive tank sender. The instrument works with both 12 V and 24 V systems and has a selectable signal for senders with a 240–33 Ω or 0–190 Ω resistance range.
The scale shows the fuel level from E/Empty to F/Full with markings at 1/4, 1/2, and 3/4. The black dial has built-in red LED backlighting, which makes the display easier to read in low-light conditions. This variant features red backlighting only.
The front diameter of the instrument is Ø 57 mm, and it is mounted in a round panel hole of Ø 51 mm. The installation depth is 45 mm, so these dimensions should be checked against the available space behind the instrument panel before mounting.
A pre-assembled connector with a five-wire harness is connected to the back. During installation, use the positive supply, negative/ground, the wire for the red backlighting, and one of the two signal wires. The selected signal wire must correspond to the tank sender's signal standard of either 240–33 Ω or 0–190 Ω.
Compatibility depends on the tank sender's resistance signal, the system voltage, and the instrument's mounting dimensions. Therefore, please check the sender standard and panel dimensions before installation.
Key featuresAnalogue fuel level display
Selectable 240–33 Ω or 0–190 Ω sender signal
For 12/24 V systems
Black dial with polished bezel
Red LED backlighting
Front diameter: Ø 57 mm
Mounting hole: Ø 51 mm
Installation depth: 45 mm
