This digital hour meter is intended for panel mounting and records as well as displays the total operating hours of equipment. The variant features a black dial, a black bezel, and a measuring range from 0 to 99,999 hours.
The hour meter can be used in both 12 V and 24 V systems. Red and yellow backlighting illuminates the instrument display and supports reading under changing light conditions.
The instrument's outer diameter is 57 mm. Mounting requires a panel cutout of Ø 51 mm as well as space for an installation depth of 45 mm. Therefore, check both the hole diameter and the space behind the panel before installation.
The digital recording of operating hours makes the instrument suitable for tracking the total operating time of engines or other compatible equipment, for example, as a basis for planning service intervals.
Key featuresDigital recording and display of operating hours
Measuring range: 0–99,999 hours
For 12/24 V systems
Red and yellow backlighting
Black dial and black bezel
Outer diameter: 57 mm
Panel cutout: Ø 51 mm
Installation depth: 45 mm
Panel mounting
