This Guardian tachometer for diesel engines with white dial and white bezel is a panel-mounted marine instrument for 24 V systems. The instrument measures engine speed from 0 to 4000 rpm and receives the rotation signal from the generator's W-terminal.
The instrument has a front diameter of 96 mm and requires a panel cutout of Ø 85 mm. Dimension P is 60 mm and can be used as a guide for installation depth. The standardized instrument dimensions make the model suitable for many existing marine instrument panels with corresponding measurements.
The instrument housing is made of nylon and fiberglass. The movable bayonet bezel can be replaced, and the design allows for mounting with a screw/locking ring or flush mounting with the series' special fastening system. When mounting behind the instrument panel, the glass can be positioned flush with the panel surface.
The white instrument dial features natural light illumination, while the scratch-resistant instrument glass protects the display. The construction is completely waterproof, although no numerical IP rating is specified.
A chrome-plated bezel with item no. 27.455.01 can be used as a documented optional accessory for this variant.
Key featuresFor 24 V diesel engines
Measuring range: 0–4000 rpm
Signal from generator's W-terminal
White instrument dial and white bezel
Front diameter: 96 mm
Panel cutout: Ø 85 mm
Dimension P: 60 mm
Housing made of nylon and fiberglass
Replaceable bayonet bezel
Scratch-resistant glass and waterproof construction
