Square deck filler in a long version for diesel refueling on boats and other vessels. The 38 mm neck is designed with a curved, ribbed connection, while the cover's clear Diesel marking helps identify the correct filling point.
The deck filler features a flip-open system and a thin 3.5 mm profile above the deck. The square flange measures 75 × 65 mm and provides a discreet, flush integration into the deck.
The construction is made of AISI 316 stainless steel with a mirror-polished surface. The material and surface finish are suitable for visible mounting in a maritime environment.
The long version has a total length of 156.2 mm. The flange is mounted with four Ø 4.5 mm screw holes. The hole center distance is 52 mm horizontally and 45 mm vertically.
The product is specifically intended for diesel and must not be confused with the SQUARE variants for water or waste. Check the neck diameter and the specified mounting dimensions before installation.
Key featuresLong SQUARE version for diesel refueling
38 mm neck with curved, ribbed connection
Flip-open top and 3.5 mm thin profile
Mirror-polished AISI 316 stainless steel
Square flange of 75 × 65 mm
Total length of 156.2 mm
Four mounting holes of Ø 4.5 mm
Hole spacing of 52 × 45 mm
