This mounting counter-flange is intended as a mating/backing flange for a recessed socket for Ø38 mm carbon fiber poles in a bimini pole system. The separate counter-flange is made of stainless steel and supports a stable flush mounting of the corresponding socket.
The counter-flange has an outer diameter of 95 mm and a central opening of Ø57.5 mm. Four mounting holes with a diameter of 7 mm are positioned on a hole circle with a diameter of 74 mm. Screw type and screw dimensions are not specified.
The product is sized for the recessed sockets with item no. 46.815.00 and 46.815.01, which are part of the system for Ø38 mm carbon fiber poles. It is not documented as compatible with the Ø50 mm sockets 46.820.00 and 46.820.01, which have different mounting dimensions.
This product is the mounting counter-flange itself and not a complete recessed socket. Rotating cover, drain connection, and socket depth are therefore not features of this separate variant.
Key featuresMating/backing flange for recessed socket
For Ø38 mm carbon fiber pole system
Made of stainless steel
Outer diameter: 95 mm
Central opening: Ø57.5 mm
Hole circle: Ø74 mm
4 mounting holes of Ø7 mm
Compatible with recessed socket 46.815.00 and 46.815.01
