This flush-mounted deck filler in mirror-polished AISI 316 with a 30° angle is designed for filling diesel into the boat's fuel tank. The diesel variant has a neck/spigot diameter of 50 mm and a flange diameter of 88 mm.
The deck filler is manufactured from AISI 316 stainless steel with a mirror-polished finish. The flush-mounted design allows for flat mounting on the deck, while the 30° angled hose spigot leads the connection away from the deck surface.
The round flange has three mounting holes. Cutout diameter, bolt circle, screw dimension, and total mounting depth are not specified and should therefore be checked against the specific installation.
The cover is opened with universal key type 20.169.90. The key is a separately documented operating tool; it is not documented as being included.
Key featuresFor diesel filling
Flush-mounted deck installation
Mirror-polished AISI 316 stainless steel
30° angled neck/hose spigot
Neck/spigot diameter: 50 mm
Flange diameter: 88 mm
Round flange with three mounting holes
Opened with universal key type 20.169.90
