Water level gauge 240–33/0–190 Ω, 12/24 V, black dial/black bezel, red backlight

Mærke: Osculati SKU: 27.320.04

Price:
Sale price208,00 kr

Description

This water level gauge is an analog panel instrument for displaying the water level in a tank. This variant features a black dial, black bezel, and red backlighting.

The instrument operates with a resistive level sender and can be set to the signal range of 240–33 Ω or 0–190 Ω. It can be used in both 12 V and 24 V systems, so the sender's resistance curve must be chosen in accordance with the instrument's selected signal setting.

The instrument's outer diameter is 57 mm, and the catalog-specified installation depth is 45 mm. The catalog measurement for the panel hole is Ø51 mm, while the installation instructions prescribe a practical panel cutout of Ø52 mm. There must be at least 55 mm of clearance behind the panel, and the permissible panel thickness is 0.5–20 mm.

The instrument is mounted from the front through the round panel hole and secured with a ring from the back. The instrument housing has an alignment pin, the position of which should be marked before mounting. The wiring harness is connected to the connector on the back after securing.

The wire connections are black to the level sender, red to the positive terminal, blue to ground or negative, and orange to the red instrument lighting. This variant only has red backlighting.

For installation in a 24 V system, use the shown voltage-reducing circuit with a 150 Ω resistor in the instrument's positive supply and a 2 kΩ resistor in the lighting circuit. The installation must be performed in accordance with the instrument's wiring diagram.

Key features

Analog display of tank water level
Selectable signal: 240–33 Ω or 0–190 Ω
For 12/24 V systems
Black dial and black bezel
Red backlighting only
External instrument diameter: 57 mm
Panel cutout according to installation instructions: Ø52 mm
Secured with a ring from the back

Did you know?

... that many of our products can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Did you know

... that many of our items can be ordered online and picked up in our self-service stores?

See more here: Self-service stores

Alpina Marineudstyr

Ask us about the product

Send us your question. The product will automatically be included in your message.

Water level gauge 240–33/0–190 Ω, 12/24 V, black dial/black bezel, red backlight
Water level gauge 240–33/0–190 Ω, 12/24 V, black dial/black bezel, red backlight Item no. 27.320.04

Description

Produkt: Vandstandsindikator
Produkttype: Analogt tankniveauinstrument
Anvendelse: Visning af vandniveau i tank
Volt: 12/24 V
Diameter: 57 mm
Dybde: 45 mm
Farve: Sort skive og sort frontring
Signal: Valgbart 240–33 Ω eller 0–190 Ω
Baggrundsbelysning: Rød
Panelhul: Ø51 mm (katalogmål)
Udskæringshul: Ø52 mm (installationsmål)
Paneltykkelse: 0,5–20 mm
Frirum bag panel: Mindst 55 mm
Montering: Frontmontering med fastspændingsring fra bagsiden
Kompatibilitet: Resistiv vandniveaugiver med 240–33 Ω eller 0–190 Ω signal
