Water level indicator for analog display of the water level in a tank. The instrument uses a 240–33 Ω sensor signal and is intended for 12 or 24 V installations.
The analog needle and the E–F scale provide a direct reading from empty to full. The black dial features a clear water symbol as well as red and yellow backlighting, so the level can also be read under changing light conditions.
The instrument has a black bezel and an outer diameter of 57 mm. It is mounted as a flush-mount instrument in a round panel hole with a diameter of 51 mm. The instrument depth P is 45 mm.
The water level indicator must be connected to a compatible water level sensor that provides a 240–33 Ω signal. The variant has a fixed signal range and is not intended for sensors with a 0–190 Ω or 10–180 Ω signal.
Key featuresAnalog water level display from E to F
Fixed sensor signal of 240–33 Ω
For 12/24 V installations
Black dial and black bezel
Red and yellow backlighting
Outer diameter: 57 mm
Panel hole: Ø51 mm
Instrument depth P: 45 mm
