This water level gauge is an analog panel instrument for displaying the water level in a tank. The instrument is designed for a fixed resistive sensor signal of 240–33 Ω and features a white dial with a polished bezel.
The instrument operates at 12/24 V and has red and yellow backlighting, allowing the scale to be read in various lighting conditions. The fixed signal range means that the level sensor must provide 240–33 Ω; sensors with 0–190 Ω or 10–180 Ω cannot be connected directly without a documented signal converter.
The front has an external diameter of Ø 57 mm. The instrument is mounted in a round panel hole of Ø 51 mm and requires an installation depth of 45 mm.
The housing is made of technopolymer, while the polished bezel is made of AISI 316 stainless steel. The construction is IP67-rated and features a convex, clear, and anti-fog treated lens. The rear connection is pre-calibrated and made with a bayonet connector.
In terms of signal, the instrument can be combined with 240–33 Ω level sensors, including the 27.160.xx and 27.170.xx sensor families for water. The sensor's length and flange must be selected according to the depth and construction of the tank.
Key featuresAnalog water level display
Fixed sensor signal: 240–33 Ω
Supply: 12/24 V
White dial and polished bezel
Red and yellow backlighting
Front diameter: Ø 57 mm
Mounting hole: Ø 51 mm
Installation depth: 45 mm
IP67-rated construction
Anti-fog treated lens and bayonet connection
