Water temperature gauge 40–120 °C is an analog, panel-mounted engine instrument for displaying water temperature in marine installations. This variant features a white instrument dial, polished bezel, and a clear temperature scale in °C.
The instrument can be used in 12 or 24 V electrical systems and is connected to an external water temperature sensor via the signal wire. For 24 V operation, the installation must be completed with the indicated resistor setup of 150 Ω and 2 kΩ. The red wire is used for the positive supply, blue for ground, and black for the signal from the temperature sensor.
The backlight can be set to either red or yellow. The orange wire activates the red lighting, while the yellow wire activates the yellow lighting. This allows the instrument lighting to be matched to the rest of the instrument panel.
The instrument has an external diameter of 57 mm and a depth of 45 mm. The nominal mounting hole is specified as Ø51 mm, while the panel cutout for installation should be Ø52 mm. There must be at least 55 mm of free space behind the panel, and the mount supports a panel thickness of 0.5–20 mm.
Installation is performed from the front of the panel. The rear fastening ring is removed, the instrument is inserted through the round panel hole and oriented using the alignment tab. The fastening ring is then tightened from the rear, after which the wiring harness is connected to the instrument's rear port.
The housing and frame are made of technopolymer, while the polished bezel is made of polished AISI 316 stainless steel. The instrument features convex, anti-fog treated glass and an IP67 protection rating.
Key featuresAnalog water temperature display with scale from 40 to 120 °C
White dial and polished bezel
For 12/24 V systems
Choice between red and yellow backlight
External diameter: 57 mm
Nominal mounting hole: Ø51 mm
Recommended panel cutout: Ø52 mm
Depth: 45 mm
Panel mounting with rear fastening ring
Protection class: IP67
