Water temperature gauge for panel mounting with analog display of engine water temperature from 40 to 120 °C. This variant features a black dial, polished bezel, and red and yellow backlighting, which makes the scale readable under various lighting conditions.
The instrument can be used in 12 or 24 V electrical systems. It has an external front diameter of Ø57 mm and is mounted in a Ø51 mm panel hole. The required installation depth is 45 mm, so dimensions should be checked against the available space behind the instrument panel.
The instrument housing is made of technopolymer, while the polished bezel is made of AISI 316 stainless steel. The convex, transparent lens is anti-fog treated, and the construction is IP67 rated. The electrical connection is made via a pre-calibrated bayonet connector on the back.
The water temperature gauge is intended for use with VDO sensors. No specific sensor number is indicated for this variant, and the sensor must therefore be selected based on the specific engine installation and its electrical characteristics.
The instrument complies with EMC Directive 2014/30/EU as well as the standards EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2006 + A1:2009 + A2:2009, and EN 61000-3-3:2013.
Important featuresAnalog measurement of water temperature from 40 to 120 °C
For 12/24 V electrical systems
Black dial with polished bezel
Red and yellow backlighting
Front diameter Ø57 mm
Panel hole Ø51 mm and installation depth 45 mm
IP67-rated construction
Anti-fog treated, convex lens
Bezel in AISI 316 stainless steel
Pre-calibrated bayonet connector
