Zipwake KB400-E CHINE - complete trim system for chine installation

Mærke: Zipwake SKU: 2012214

Price:
Sale price39.375,00 kr

Description

Zipwake KB400-E CHINE is a complete trim and stabilization system with everything you need for a professional installation. The system is developed for boats with chines, where the interceptor's geometry ensures proper water contact and effective lifting force when mounted on the hull chine.

The system includes a pair of Series E interceptors as well as a control panel, distribution unit, integrator module, and all necessary cables. Series E is suitable for medium to larger boats where fast automatic trim, stabilization, and improved comfort while cruising are desired.


Included in the box

  • 2x IT400-E CHINE - 400 mm interceptors with cables and covers
  • CP-E Control Panel - With 7 m cable
  • DU-E Distribution Unit - With 6 m power cable (12 AWG)
  • Cables and accessories - All necessary mounting hardware

System specifications

  • Interceptor length: 400 mm
  • Blade stroke: 60 mm for effective lifting force and trim response
  • Blade rate: 40 mm/s for fast and stable automatic regulation
  • Operating voltage: 12-32 V DC
  • Max boat speed: 60 knots

Installation and expansion

The interceptors are supplied with a 3-meter PUR cable and an M12 5-pin connector (14.5 mm diameter), which can be extended up to 6 meters. The chine version is intended for mounting on the hull chine for the correct angle relative to the water flow and optimal stabilizing effect.

Did you know

... that you can see our large exhibition and try out Garmin and Zipwake products on our "Showboat" in our large boat equipment store at Bådebyggervej 1 in Næstved. Furthermore, many of our items can be ordered online and picked up in our self-service stores locally in the Danish harbors.

See more here: Self-service stores

Installation/mounting

Have your Zipwake equipment installed by our skilled specialists - call us at 71 99 77 79 so we can find a solution together.

Alpina Marineudstyr

Ask us about the product

Send us your question. The product will automatically be included in your message.

Zipwake KB400-E CHINE - complete trim system for chine installation
Zipwake KB400-E CHINE - complete trim system for chine installation Item no. 2012214

Description

Produkt: Zipwake KB400-E CHINE - Kit Box 400 E Chine
Model: KB400-E CHINE (SKU: 2012214)
Vægt: 39.375 kg (86.81 lbs)
Indhold: Komplet system med 2x IT400-E CHINE interceptors, CP-E control panel, DU-E distribution unit, kabler og tilbehør
Tekniske specs:
- Kabellængde: 3 m (forlænges til 6 m)
- Kabel materiale: PUR
- Connector: M12 5-pin circular, 14.5 mm
- Max bådhastighed: 60 knots
- Driftsspænding: 12-32 V DC
- Strømforbrug: 25 W max/servo unit
- Driftstemperatur: 0° til +40°C
- Vandtæthed: IP68 5 m (16 ft)
- Certificering: CE, FCC
